Jomox T-RACKONIZER Bedienungsanleitung Seite 8

User Interface Analog Section
Gain:
This adjusts the sensivity of the input. If the signal overloads the input, all
8 LEDs of the program selection will light up. However, the unit has
considerable headroom and is quite resistive to overloading. You can
(ab)use the distortion of filters creatively without having to fear that the T-
Rackonizer will be damaged.
LFO Intensity:
Controls the intensity of the LFO/envelope signal. At center position, the
intensity is zero. When you turn to the left, the resulting modulation signal
is a combination of audio envelope and LFO. The envelope masks the LFO.
So, the signal is dependent on the input signal and the LFO.
E n v e lo pe
E n v + LF O
Turning to the right controls the LFO running freely on its own, fully
independent of the audio signal.
L F O
The sine LFO wave is re-triggered by peaks in the audio signal. The
threshold itself is fixed, but it can be varied by the adjustment of the Gain
control.
LF O
R e st art
A U D I O
8 T-Rackonizer Operating Manual
