Connecting
Positions on RG 10:
F :
6 Signalground
G :
1 Setting (set point value)
H :
2 Room temp (actual value)
RG 10 is connected as follows. (See corresponding
Installation and Maintenance Instructions for terminal
block positions.)
FIGHTER 300/301/400/401
F -> Terminal block 14, F
G -> Terminal block 14, G Channel 4
H -> Terminal block 14, H Channel 5
FIGHTER 310P/410P
F -> Terminal block 14, 4
G -> Terminal block 14, 5 Channel 15
H -> Terminal block 14, 6 Channel 16
FIGHTER 360P
F -> Terminal block 14, 13
G -> Terminal block 14, 16
H -> Terminal block 14, 12
EVC 240, EVP 270
F -> Terminal block 14, –
G -> Terminal block 14, Set
H -> Terminal block 14, Actual
EVC 13
F -> Terminal block 14, 4
G -> Terminal block 14, 5
H -> Terminal block 14, 6
FIGHTER 1140/1240/1250
F -> Terminal block X1, 4
G -> Terminal block X1, 14
H -> Terminal block X1, 3
FIGHTER 1330
F -> Terminal block X1, 13
G -> Terminal block X1, 14
H -> Terminal block X1, 12
