Danger source
Fundamental safety infor-
mation disregarded
The following applies to all
work on voltage-carrying
equipment:
Only qualified personnel are
allowed to work on electric
devices!
Intended use
disregarded
Description of use
disregarded.
Type plate information
disregarded
Installation/
maintenance work
High brightness of the
flash function.
AC version
X1
Light intensity control
(15 – 100%)
Operating voltage
connection
S1
Operat-
ing mode
1
2
3
no.
1
Flashing light
OFF OFF OFF
2
OFF OFF ON
Flashing light
3
Continuous light
OFF ON
OFF
4
Blinking light
OFF ON
ON
5
Flashing light
ON OFF OFF
6
Blinking light
ON OFF
ON
7
Flashing light
ON ON
OFF
8
Flashing light
ON ON
ON
*
Factory setting
04/2019
Safety information / Quick guide Quadro LED-HI-3G/3D
Danger
Degree of risk / Possible consequences / Countermeasures
DANGER - Danger to life due to electric shock
Voltage-carrying devices and exposed connection cables may cause electric
shocks and serious accidents.
➢ Only trained and authorized electricians may work on electrical connec-
tions.
➢ Disconnect all supply lines from the mains before installation and secure
them against reconnection. Always ensure absence of voltage.
➢
The operating voltage must only be applied when the housing is firmly
closed
WARNING - Danger due to unauthorized use of the devices
Improper use may lead to serious accidents.
➢
Ensure that the connection cable is protected against pulling and twist-
ing during installation.
The devices are only intended for fixed installation.
DANGER - Hazard due to damage to the devices
Non-compliance with the information on the type plate can lead to
serious accidents.
➢ Always observe the information on the type plate when installing and ser-
vicing the devices.
➢
Observe the chemical resistance of the polycarbonate plastic.
CAUTION - Risk of injury due to sharp edges or
heated components
➢ Wear gloves during any installation, assembly or service/maintenance
work.
➢
Perform wiring tasks at a distance from sharp edges, corners and internal
components.
CAUTION
➢
Avoid constant, direct glances into the activated lights to prevent impair-
ment of vision.
S1 Operating mode selection
0.75 Hz
*
1 Hz
1 Hz
2 Hz
2 Hz
0.1 Hz
0.5 Hz
.
X1
X2
External control input
Operat-
S1
ing
mode
1
2
3
no.
OF
OF
OFF
1
F
F
OFF OF
2
ON
F
OFF ON OF
3
F
OFF ON ON
4
ON OF
OF
5
F
F
ON OF
ON
6
F
ON ON OF
7
F
ON ON ON
8
Switch position S1.4 for external control: ON
*
Factory setting
Page 2/2
DC version
Operating voltage connection
X1
S1
Light intensity
Operating mode
control (15 -100%)
selection
... to operating mode
Readiness for
external control
Flashing light
1 Hz
*
Continuous light
Blinking light
1 Hz
Flashing light
2 Hz
Blinking light
2 Hz
Flashing light
0.1 Hz
Flashing light
0.5 Hz
Switchover by ...
C1
C2 C1 + C2
no.:
3
2
4
4
--
4
--
4
4
--
--
--
7
6
8
8
--
8
--
8
8
--
--
--
086050004
