6. Montage/Inbetriebnahme
Vor Einbau des Membrantrockners Leitungen gründlich reini-
gen (z.B. durch Ausblasen).
Einbaurichtung von Filtern und Membrantrockner beachten
(vgl. Kennzeichnung der Durchflussrichtung auf dem Typen-
schild und den Filterköpfen).
7. Befestigung DRYPOINT M
Die Befestigung sollte über Wandhalter der vorgelagerten
CLEARPOINT-Filter oder die Rohrleitungen erfolgen.
Die Befestigung so anbringen, dass beim Wechsel der Fil-
terelemente keine Beschädigungen am Membrantrockner
auftreten können.
8. Dichtmittel
Achtung: Alle Gewinde vor und am DRYPOINT M- Druckluft-
Membrantrockner mit Teflonband eindichten. Keine flüssigen
Dichtmittel benutzen.
9. Spülluft
Die Spülluft muss ungehindert aus den Bohrungen austreten
können.
10. Installationsort
Aufstellungsraum bzw. darin enthalten Anlagen und Ausrü-
stungen oder gelagerte Materialien dürfen nicht chemisch
aktive Stoffe freisetzen.
english
1. Liability for defects
Please read this information very carefully:
Liability for defects can only be accepted if the following rules
and the instructions for installation are complied with.
Provided appropriate CLEARPOINT filters are being used and
the filter elements are replaced once a year, the purchaser of
the compressed-air membrane dryer shall be entitled to claim
remedy of defects within 2 years from date of invoice.
BEKO shall not be liable for damage due to improper or incor-
rect use, wear, storage or other actions by the purchaser or
third parties.
This applies in particular to wearing parts.
2. Temperature
There must be no danger of frost at the place of installation; the
temperatures at the place of installation and of the compressed
air should be between +2 and + 60 °C.
DRYPOINT DM 08-14 R, 08-19 R, 08-23 R, 08-29 R
Wichtige Hinweise • Important information
3. Filters
Please observe the relevant filter requirements (see page
8 - 9):
Dirt particles, oil residues and liquid condensate have to be
safely retained.
This requires the provision of a CLEARPOINT S super fine filter
(0.01 µm). With high dirt loads or large amounts of condensate,
it will be necessary to install a CLEARPOINT F fine filter (1 µm)
in addition and, where appropriate, a W water separator.
Caution: The filter elements need to be replaced once a
year.
Caution: maintenance works must be carried out only when
the device is pressureless!
4. Pipe between filter and membrane dryer
The membrane dryer must be located directly downstream
of the last CLEARPOINT filter in order to avoid renewed
condensate formation. If a connection has to be installed
between the filter and the DRYPOINT M device, this must
be made of non-corroding material! Note: Do not use any
galvanized pipes or fittings between filter and membrane
dryer (corrosion)!
5. Shutoff units
The shutoff elements must not be opened suddenly. It is rec-
ommended to install a bypass around the unit.
6. Installation/putting into service
Clean the pipes thoroughly (e.g., by blowing through them)
before installing the membrane dryer.
Observe the installation direction of filters and membrane dryer
(see marking indicating the direction of flow on the type plate
and the filter heads).
7. Mounting of DRYPOINT M
The device should be mounted using wall brackets of the
upstream CLEARPOINT filters or the piping system.
Ensure that replacement of the filter elements cannot damage
the membrane dryer.
8. Sealing material
Note: Use Teflon tape to seal off all threaded connections
upstream of the DRYPOINT M membrane dryer and on the
device itself. Do not use any liquid sealants.
9. Purge air
The purge air must be able to flow freely out of the orifices.
10. Place of installation
The room of installation, plants and equipments in this room,
or stored materials must not release chemically active materi-
als.
