Specifications cont.
Monitor
Specifications
Picture Tube
Viewable Image Size:
Input Signal
Analog input:
Display Colors
Horizontal:
Synchronization
Range
Resolutions Supported
Resolution based on horizontal and
vertical frequencies only
Horizontal:
Active Display Area
(Factory Setting)
Active Display Area
(Full Scan)
Power Supply
Current Rating
Dimensions
Weight
Environmental Considerations
Operating Temperature:
Storage Temperature:
78135162.wpc
MultiSync ® FP
Monitor
Diagonal: 22 inch/55.3 cm
20 inch/50.8 cm
Radius: 57800 mm
Video: ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. (Positive/Negative) (TTL Level)
Sync on Green video (Positive) 0.7 Vp-p and sync.
(Negative) 0.3 Vp-p
Unlimited number of Colors
31 kHz to 130 kHz
Vertical: 55 Hz to 160 Hz
640 x 480 @ 60 to 160 Hz
800 x 600 @ 55 to 160 Hz
832 x 624 @ 55 to 160 Hz
1024 x 768 @ 55 to 154 Hz
1152 x 870 @ 55 to 137 Hz
1280 x 1024 @ 55 to 118 Hz
1600 x 1200 @ 55 to 102 Hz .................... NEC cites recommended resolution a
1792 x 1344 @ 55 to 91 Hz
1800 x 1440 @ 55 to 85 Hz
1856 x 1392 @ 55 to 88 Hz
1920 x 1440 @ 55 to 85 Hz
2048 x 1536 @ 55 to 80 Hz
396 mm/15.6 inches
Vertical: 297 mm/11.7 inches
406 mm/16.0 inches
305 mm/12.0 inches
AC 100 – 120 V/220 - 240 V, 50/60 Hz
2.4A @ 100 – 120 V / 1.1A @ 220-240 V
483 mm (W) x 501 mm (H) x 472 mm (D)
19.0 inches (W) x 19.7 inches (H) x 18.6 inches (D)
32.4 kg
71.4 lbs
+10°C to +35°C/+50°F to +90°F
Humidity: 30% to 80%
Altitude: 3,000 m/10,000 Feet
-20°C to +60°C/-4°F to +140°F
Humidity: 10% to 90%
Altitude: 13,700 m/45,000 Feet
NOTE: Technical specifications are subject to change without notice.
14
16
™ Notes
1370
90° deflection, 0.24 grille pitch, medium
short persistence phosphor, aperture
grille CRT, multi-layered, anti-static screen
coating, semi-dark-tint screen, and
OptiClear screen surface.
®
Depends on display card used.
Automatically
Automatically
Some systems may not support
all modes listed.
85 Hz for optimal display performance
Dependent upon signal timing used,
and does not include border area.
Dependent upon signal timing used,
and does not include border area.
