USB connectors
3
You can connect peripherals such as scanners, printers and keyboard to the USB
(Universal Serial Bus) connectors. USB peripherals are hot swappable enabling plug
and play for your peripherals.
LAN connector (RJ 45)
4
Connects the RJ-45 cable for 10/100/1000 Base Ethernet connection to this port.
Audio jack
5
An external amplified speaker may be connected to the jack for listening to sounds.
DC inlet Jack (for AC adaptor)
6
To supply power to the system, please connect here the supplied AC/DC power adaptor
(12V/5A).
DC outlet Jack (for future usage)
7
Cash Drawer Ports(2*3 pin Molex)
8
Optional Sharp cash drawers can be connected to the cash drawer port.
Parallel Port
9
Connect parallel devices such as a printer to the parallel port.
HDD rear cover
10
Remove the cover to install or replace the HDD. Consult your authorized SHARP dealer
for further details.
