SYSTEM OVERVIEW

Front view
1
2
Operation Display (Touch Panel)
1
15 inch TFT-LCD screen with touch sensitive screen. Displays the operational status of
the system and the system can be adjusted by touch screen.
Power button
2
After the terminal has been connected to the AC power supply push the power button
to turn on the terminal.
HDD indicator
3
LED lights up when the hard disk drive is reading data from or writing data to the drive.
Power indicator
4
LED lights up when the system is on
4
3 4 5
6
