Hella KLX 1 LED Montageanleitung Seite 13

EN
ENGLISH
Introduction:
Industrial trucks of highly varying types are in
use in large areas and in close quarters, in halls
as well as outdoor areas.
Versions:
• Permanently attached beacons with stranded
connection wires and base
• Magnetically attached beacons with connection
cable and plug
13
Applications:
Important:
This line of beacons is intended for applications
where the vehicles do not leave enclosed com-
pany grounds and are not used in street traffic.
e.g.:
• Fork lifts
• Sweeping and construction machines
• Distribution vehicles
Technical Data
Type approval: ECE-R10
Rated voltage 12 V / 24 V
Operating voltage 9-30 V
Total current approx. 0.2 A - 0,5A
consumption
Power approx. 4 W
consumption
Dome PC
Operating position Upright
Protective rating IP67, IPX9K
Temperature range minus 40 ºC to plus 60 ºC
Inverse polarity yes
protection
Housing PC + ABS
Interference CISPR25 Class 3
suppression class
