Choose Run Mode
MENU
The operating mode is set in menu RUN. For operation on a DMX-controller DMX needs to be
set. SLAV sets the fixture into slave mode.
Edit User Programs
MENU
In the menu EDIT the user programs PR.C1 to PR.10 can be edited.Every program can have up to
30 steps (SC.01-SC.30). Every step persists of the parameter colours RGBW (R./G./B./W.), Zoom (Z.)
STROBE (S.)„0-20Hz", TIME (T.) and FADE (F.). User programs can be transfered to other fixtures
(see master/slave).
Step-by-step programming of the custom stand-alone programs with up to 30 different steps.
NOTE: For less than 30 steps the TIME (T.) and FADE (F.) of the last step needs to be set to 0.
Downloaded from www.Manualslib.com
RUN HSIC DMX
PERSON
HSIC SLAV
HSIC EDIT PR.C1
PR.C2
o
o
o
PR.10
Example for time settings of a stand-alone programm with 3 steps:
Step 1 T. = 4
Step 2 T. = 5
Step 3 T. = 0
manuals search engine
SC.01 R.(0 - 255)
G.(0 - 255)
SC.02
o
B.(0 - 255)
o
W.(0 - 255)
o
Z.(0 - 255)
SC.30
S.(0 - 20)
T.(0 - 255)
F.(0 - 255)
F. = 3
F. = 2
F. = 0
E-27
