English
Application
Access door loudspeaker controller
with line rectifier in switch panel
housing as an interface for the con-
nection and power supply of door
components to the Access network.
Application
The combination of ATLC 670-...
with ANG 600-... can only be used
in connection with Siedle Access.
The devices are used for connection
and power supply to the door sta-
tion and/or the assigned camera.
Any other application is deemed not
in accordance with its intended use
and exonerates the manufacturer
from any liability.
Danger
Mounting, installation and servicing
work on electrical devices may only
be performed by a suitably qualified
electrician. Failure to observe this
regulation could result in the risk of
serious damage to health or fatal
injury due to electric shocks.
• In a building installation, an all-
pole mains switch with a contact
opening of at least 3 mm must be
provided. The device must not be
exposed to water drops or sprayed
water! Ensure sufficient ventilation,
paying particular attention that ven-
tilation slits are not covered.
• For surface mounting, ensure that
"protection against direct contact"
with active parts is provided. For
details, consult VDE 0100/DIN 57100
part 410.
• When using stranded core as cable
material, this must be fitted with
wire end ferrules without fail.
• With a 120 V supply, the line recti-
fier may only be operated in a closed
switch cabinet. Covering solely with
the ZAP 6-0 is not sufficient. With a
120 V supply, the line rectifier may
only be used in conjunction with ITE
devices. (Information Technology
Equipment)
4
Scope of supply
ATLC/NG 670-... comprises:
• ATLC 670-... Access door
loudspeaker controller for top hat
rail mounting
• ANG 600-... Access line rectifier
for top hat rail mounting
• This product information
Mounting
The two devices ATLC 670-... and
ANG 600-... are connected using
the provided ribbon cable prior to
mounting.
Mounting in distribution cabinet
1 Clip the two devices onto the top
hat rail.
Surface mounting
(only in 230 V mains)
2 Mounting is only admissible using
accessory ZAP 6-0. Engage the
provided catches on the back of the
device ATLC/NG 670-... . Mount the
devices on the wall.
With different mains voltages,
mounting in suitable distribution
boxes is admissible.
Installation and commissioning
Installation is described in the Siedle
Access System Manual which is sup-
plied with the server and can also be
downloaded from the website.
Commissioning takes place as
described in the quotation.
Terminal assignment
ATLC 670-...
S1 power supply and audio
S2 transmission
S3
S4
D1 data transmission with
D2 digital call and Vario bus
data transmission
V1 video signal
V2 (two-wire FBAS)
15 input via potential-free
16 contact
E or
17 input galvanically isolated
18 4-30 V DC, 10 mA
13 switching contact
14 A2 30 V AC/DC, 2 A e.g. for
light contact
23 output (door release)
24 AC/DC programmable
A1
10-16 V AC max. 700 mA,
13 V DC max. 300 mA
ANG 600-...
L 100 V to 240 V AC,
N +/- 10%, 50/60 Hz
PE
+ output voltage
- 48 V DC 800 mA
11 changeover contact
12 A3 250 V 6 A, circuit breaker
14 with max.10 A
Specification of the changeover
contact
• Contact load at least
5 V, 100 mA
10 V, 10 mA
24 V, 1 mA
• Admissible switching outputs:
Motor max. 3 A
bulbs max. 1300 W
Energy saving lamps max.
18 x Silvania 7 W or
12 x Osram 11 W
Fluorescent lamps uncompensated
cos j 0.5 max. 800 VA Duo fluores-
cent lamps max. 1200 VA
Parallel compensated fluorescent
lamps max. 400 VA
Iron core transformers for low-vol-
tage halogen lamps max. 1000 W
Electronic transformers for low-vol-
tage halogen lamps max. 1300 W
