Figure 4: Web browser interface

Live view mode

Live mode is the normal operating mode of
the unit where you watch live pictures from
the cameras.
Regularly used functions in live view can be
quickly accessed by clicking the left-button of
the mouse when its cursor is on the camera
image. The live view toolbar appears. See
Figure 3 on page 4 for a description of the
functions available.
Configuring the recorder
The recorder has an icon-driven menu
structure that allows you to configure the
unit's parameters. Each command icon
displays a screen that lets you edit a group of
settings. Most menus are available only to
system administrators.
Refer to the recorder user manual for detailed
information on configuring the unit.
To access the main menu from live view:
• Press the
control or front panel.
- Or -
• Right-click the mouse and select
from the pop-up menu.
The main menu screen appears. Move the
mouse over a command icon in the menu
toolbar and click to select it.
EN 6
Downloaded from www.Manualslib.com
Menu
button on the remote
Menu
manuals search engine
Description of the command icons in the
menu toolbar:
Configures display settings.
Configures analog and IP camera
settings.
Configures standard network
settings.
Configures recording settings.
Configures alarm and event settings.
Configures system settings.
Configures storage management.
Configures user settings.
View system information.
Provides reference information to the
various toolbars and menus within
the interface.
Provides access to logout, reboot
and shutdown options.

Specifications

Power supply:
Power consumption (without HDD):
TVR 4508HD
TVR 4516HD
Operating temperature:
TruVision DVR 45HD Quick Start Guide
100 to 240 VAC,
6.3 A, 50 to 60 Hz
≤ 45 W
≤ 65 W
-10 to +55 ºC
(14 to 131 °F)
