EN
IMPORTANT! KEEP FOR FUTURE REFERENCE
22. Please do not use the seat if it is su ered from an accidient even though it is not broken and looks "well", please abondon it and
use a new one.
23. Please must use the seat cushion in Group 0+. Please leave your baby sit on the cushion if the weight of he or she is less than
15kgs. This cushion is designed for new born baby which is not only keep baby comfortable but also could o er a certain protection.
ATTENTION:
Generally the child seat is for all vehicles eqquipped with Iso x. If the vehicle seat has some issue like seat belts are broken ets which
cause the child seat can not be installed correctly, please move it to another seat in good condition.
To shall be recommended that: a.)The child restraint shall not be used without the cover;
b.)The seat cover should not be replaced with any other than the one recommended by the manufacturer,because the cover
constitutes an integral part of the restraint performace.
WARNING!
If your child is secured in the vehicle seat with only a 2 point belts, he or she could sustain serious injuries possibly resulting in death.
Never use in connection with a 2 point belts (Figure 1). Do not fasten the child seat on the front passenger seat with validated airbag
as it will casue death or serious injury if airbag exploded. Please always secure the child seat on the rear seats.
Do not fasten the child seat on the rear facing or lateral vehicle seats. Please refer to the following graphic when you install your child
seat (Figure 2).
Please leave your baby sit on the cushion if the weight of he or she is less than 15kgs. This cushion is designed for new born baby
which is not only keep baby comfortable but also could o er a certain protection.
PARTS:
1- Height adjuster; 2-Seat back; 3- Push button adjuster; 4-Top tether hook; 5- ISOFIX connectors(x2); 6-Belt hook for group II/III;
7- ISOFIX release button (x2); 8- ISOFIX indicator; 9- Headrest; 10- Belt slots; 11-Sholder belt; 12- Crotch pad; 13- Central adjuster;
14- Webbing knob; 15-Shoulder pads(x2);16- Cushion; 17- Adjuster belt; 18- Reclining position handle; 19- Metal tongue from
vehicle; 20- Buckle from vehicle; 21- Metal tongue of the child seat; 22- Buckle from child seat; 23-Button for adjusting the rotation
angle; 24-Belt guider; 25- Side protection;
INSTALLATION IN GROUP 0+ REAR FACING:
Fastened by ISOFIX+TOP TETHER (approx for baby from birth-13kgs/birth-15 months)
The ISOFIX anchors are behind the vehicle seat where are always marked with "iso x"(Figure 1.1). Put the child seat on the vehicle
seat and adjust it in the maximal position (Figure 1.2). One hand pulls the button on the base and turn the seat around (it will be
locked in 180 degrees) with the other hand (Figure 1.3;1.4). Pull the ISOFIX connectors out at the both side of the seat and aim at the
low anchors at the bottom of the seat (Figure 1.5). Push the seat until they are locked, you will hear "click"(Figure 1.6). Hook the top
tether strap on the anchor bracket and the belt should go through the blue clip (Figure 1.7;1.8).
INSTALLATION IN GROUP I/ FORWARD FACING:
Fastened by ISOFIX+TOP TETHER (approx for baby from 9-18kgs/9 months-4years)
The ISOFIX anchors are behind the vehicle seat where are always marked with "iso x"(Figure 1.1). Put the child seat on the vehicle
seat in forward facing(Figure 2.2). Pull the ISOFIX connectors out at the both side of the seat, if it is in the locked condition, unlock it
and the indicators show in green. Aim at the low anchors at the bottom of the seat (Figure 2.1; 2.2; 2.3). Push the seat until they are
locked, you will hear "click"(Figure 2.4). Hook the top tether strap on the anchor bracket and the belt tightly. The indicator will be in
green after tighten (Figure 2.5; 2.6).
ENGLISH
