Electrical connection:
(Circuit board in the 1
Connecting terminal (X1)
AC: DC:
L/
Operating voltage
connection
N/
st
1 stage
nd
2 stage
rd
3 stage
03/2020
st
stage/ in the lower sounder part)
X1 Operating voltage connection
X2 Connector f rom light circuit
board when using common
connection of light and sounder
at 1st stage.
X3 Connector f rom light circuit
board
X4 Connector 1
X5 Connector 2
X6 Connector 3
+
-
Optical Settings
Light intensity control
st
stage
Selection of
nd
stage
operating mode
rd
stage
DC version
rd
3 stage
nd
2 stage
st
1 Stage
Tone selection switch
The desired tone can be selected using the tone selector switch S3.
The tone is generated af ter the supply voltage is applied . The possi-
ble tones are described in the tone type table in the Annex.
4/12
Quick guide PY L-S-TL/ PY L-S-TLA
(Circuit in the lens)
S1
1 2 3
OFF OFF OFF
OFF OFF ON
OFF ON OFF Continuous light
OFF ON ON
ON OFF OFF Flashing light 2 Hz
ON OFF ON
ON ON OFF Flashing light 0.1 Hz
ON ON ON
*
f actory setting
Tone settings
(on the driver board in the upper sounder part)
AC version
Volume control
S3
Operating mode
Flashing light
*
1 Hz
Flashing light 0.75 Hz
Blinking light 1 Hz
Blinking light 2 Hz
Flashing light 0.5 Hz
Tone selection switch
