LASERLUCHS PICO-TRACKER-V1 Kundenhandbuch Seite 19

2.1 Operation rotary switches
The rotary switch on the back side of the laser module has
3 options. You can take every single function from the list
below:
Position Operating mode
IR only infrared Laser is turned on
G only green laser is turned on
OFF both lasers are turned off
The rotary switch can be turned anticlockwise and clockwise
without a limit as you can see in picture 1. The conditions are
repeating alternately.
Picture 1
Status indication function
green light
green light
LED off
The functional
while using the infrared
mode can be seen by the
green LED on the back
side of the rotary switch.
status
