IKA RCT digital Servicehandbuch Seite 3

Type: IKA myplate (RCT digital)
Voltage: 115 V~
Date: 17-MAY-2017
XXXXXXXXXX XXXXXXXXXXXXXXXXXXXX
Pos Item No Bezeichnung
215 25002243 Steckverbinder-Stecker
301 25002804 BLP RCT digital
401 25002070 Motor-EC
402 25002479 Auflage
403 25001385 Luefter
404 3460800 Gewindestift
405 3409300 Magnet
406 3416300 Zahnscheibe
407 25003722 Senkschraube
1704 4220200 USB Kabel
1810 3564500 H 11 Netzkabel
1960 4049500 Schraubendreher
1996 3516800 PT 1000.60
2000 25004733 RCT digital Heizung komplett
®
IKA Service-Manual
XXXXXXXXXXXXXXXXXXXX
Description Technical data
connector male
PCBA RCT digital 115V
motor-ec
Support
fan
hexagon sock.set screw M 4,0x 6
Magnet AlNiCo
toothed lock washer V 4,3
countersunk head screw M3,5
USB cable
H 11 power cord USA
screw driver
PT 1000.60
RCT digital heating 230V complete 115V
Bemerkung
Pos 201, 202, 203, 204, 205, 206, 207, 208, 209, 210, 211, 212, 213, 214, 215
Item No.:25005389
SZ: 12000020998_b
Remark
2 / 2
