Rimage 2000i™
2.
Access the printer.
a.
b.
c.
3. Open the ink cartridge access door.
4. Use the alignment screws to align the printer.
a.
16
Downloaded from www.Manualslib.com
To access the two hex nuts at the rear of the printer, lift up the printer service door.
Note: You may need to prop this door open or have someone hold the door for you.
Using the 11/32" hex driver, loosen the two hex nuts at the rear of the printer. This loosens the
printer frame and allows you to use the alignment screws to align the printer in step 4.
Note: The purpose of the hex nuts is to hold the printer securely during shipment. Tightening
these nuts after alignment is optional.
Close the printer service door.
Loosen both of the T25 Torx screws at the front of the printer until you can move the printer side to
side.
manuals search engine
Torx Hex Torx
