Input/Output Signal Connections

No.
1
2
3.
4.
5.
6.
7.
8.
9.
10. VIDEO INPUT
11. AUDIO INPUT RIGHT
12. AUDIO INPUT LEFT
13. SCART INPUT
14. VGA INPUT
15. HDMI INPUT
16. USB INPUT
(All pictures used in this manual are only for illustration purposes. Those pictures may be different from the actual.)
Terminal
POWER SWITCH
AC POWER CORD INPUT
ANTENNA
EARPHONE OUTPUT
VGA AUDIO INPUT
COMPONENT (Cr/Pr) INPUT
COMPONENT (Cb/Pb) INPUT
COMPONENT (Y) INPUT
S-VIDEO INPUT
12
