Sistemi Elettronici
di Apertura Porte e Cancelli
International registered trademark n. 804888
2.3 Frequency adjustment and re-balancing
The actual frequency of the detector can be adjusted on two levels through DIP- switch 4.
Frequency
Low
High
The admissible frequency range is 30kHz to 130kHz. The frequency depends on the loop geometry, number of
turns, inductivity resulting from the loop supply line and the chosen frequency level.
The re-balancing can be manually triggered by changing the frequency adjustment of a channel.
As soon as switched on, the detector automatically executes an adjustment of the loop frequency. In case of a
short-term voltage toss of <O,1s no re-balancing will be executed.
Note: When plugging in the loop, respect the polarity of the connectors.
3. LED-DISPLAY
The green LED indicates that the detector is operable. The red LED indicates the activation of the relay output in
relation to the seizure condition of the loop.
Green LED Loop control
off
flashes
on
on
off

4. TECHNICAL DATA

DIMENSIONS
PROTECTION CLASS
CURRENT SUPPLY 24V DC
WORKING TEMPERATURE
STORAGE TEMPERATURE
AIR MOISTURE
LOOP INDUCTIVITY
FREQUENCY RANGE
SENSITIVITY
HOLDING TIME
LOOP LEAD IN
LOOP RESISTANCE
OPEN-COLLECTOR OUTPUT
SLOW OPERATION
SIGNAL DURATION
TIME OF DECLINE (DECREASE) / DELAY 25ms
CONNECTION
Cod. 67410730
®
Channel: DIP-switch 4
Red LED Loop condition
off
off
off
on
on
80 x 45 x 17 mm (LxWxH without plug)
IP 00
±20% max. 2,0W
-20 °C to +70 °C
-20 °C to +70 °C
max. 95 % not condensing
20-800 uH, recommended 75-400uH
30-130 Khz in 2 levels
0,01 % to 0,27 % (Äf / f)
5 min. or endless
max. 100 m
max. 20 Ohm (incl. supply line)
45V / 100mA / 100mW
50ms
> 200 ms
2x MOLEX-socket, series 3215, 5-pole
REV 01 - 03/2011
ON ON
OFF
1 1
ON ON
ON
1 1
Detector condition
No supply voltage
Alignment or frequency indication
Detector ready, loop free
Detector ready, signal indication
Loop fault
in 4 levels -
LOOP PLUG
ENGLISH
0,02 % to 0,54 % (ÄL /L)
7
