3.1 Starting the Car

The PIKO SmartMeasure Car is activated by pushing any button on the keypad for one second, or by setting the car on live track.
# 55050 will only function on 2-rail DC track, and #55060 will only function on 3-rail AC track.

3.2 Display screen side

3.2.1 Display symbols

Explaination of the symbols – upper status bar (from left to right):
1. Track power – analog
2. Data storage / memory – no test run
3. USB status – connection active
4. WLAN status – "WLAN" on
5. battery status – displayed condition corresponds with charging status
The display shows the actual measurements being taken, their value, and activated functions; i.e. "test
run active."
The current measuring function may also be indicated by an illuminated LED on the keypad on the
opposite side.
or digital
or „test run active"
or "not connected"
or "WLAN" off
33
