Safety instructions

R/C models can be dangerous and could cause
personal injury or damaged to property.
Thus, for your safety and that of others,
1. Follow all the cautions, warnings, and
instructions in this manual.
2. Be "Safety Conscious" and use common sense
at all times.
3. Remember that operating any R/C model
demands skills developed through proper
instruction and training - they are not acquired
immediately.
4. Don't run risks, such as operating your model
in adverse weather.
5. The remote control's special technology makes
the 2.4 GHz transmitter and receiver a single
unit and coordinates them together. Therefore,
the receiver is not influenced by any other
transmitter or radio signal. It is no longer
necessary to check whether other models
nearby are running on the same frequency
channel, as was the case with previous
frequencies (27/35/40 MHz).
6. Respect the rules of the track on which you
operate your model.
7. Running your model in the street is very
dangerous to both automobile drivers and your
model. Avoid running your model in the street.

Caution

Control of models is impossible with insufficient or
no voltage in the transmitter or receiver. A receiver
battery that is too weak will move the servo(s) very
slowly, and that may cause erratic operation of
your model. When using a car that
operates both the electric motor and receiver on
the same battery, such as a BEC system, you
should discontinue operating the car when the top
speed becomes sharply reduced, otherwise loss of
control will result soon afterwards.
REFLEX WHEEL 2.4GHz CARSON Radio Control System 50 050 5004
8. Never aim or direct your model car at any
person or animal. These model cars accelerate
very quickly and can cause serious physical
injury.
9. You are responsible for animal safety when
operating your model. Keep your model away
from any visible wildlife. On water, watch
carefully out for fishing lines as these may
entangle the boat's propeller or in other ways
disrupt the operation of the boat.
10. At any time during the operation of your model,
should you sense, feel, or observe any erratic
operation or abnormality, end your operation.
Do not operate it again until you are certain
that the problems have been fixed.
11.Take advantage of the failsafe setting. During a
breakdown in signal transmission (such was
when transmission voltage is too weak), this
setting shifts the model into a control mode that
prevents it from taking off uncontrolled.
Take your time to read all the way through the
pages of this booklet before starting the
installation of
this Digital Proportional Radio Control System.

Operating procedure

Many publications say that the setup sequence for
the transmitter and receiver don't play a role any-
more with 2.4 GHz sets. However, we recommend
sticking to the sequence typical for previous sets.
• Before operation: First turn on the transmitter,
then the receiver. Lastly, connect the drive bat-
tery to the control unit.
• After operation: Disconnect the battery from the
control unit. Turn the receiver off, and then the
transmitter.
• Before and after operating the transmitter,
make sure that trim is in the desired place and
that all checks have been made.
