SANUS VuePoint F80b Montageanleitung Seite 7

Werbung

Verfügbare Sprachen
  • DE

Verfügbare Sprachen

  • DEUTSCH, seite 18
For TVs with a fl at/unobstructed back.
Ensure that the bracket is level on the
back of the TV. Standard confi gurations
are shown. If you need extra space
to accommodate cables, recesses, or
protrusions, see installation option 1-2 that
uses spacers. For special applications,
or if you are uncertain about your
hardware selection, contact
Customer Service.
NOTE: For 70-80 in. TVs
spacers are required.
M4
M6
6902-002033 <01>
[02]
02
[19]
[06]
[04]
[02]
[20]
[13]
[10]
[11]
M5
M8
1-1
[03]
[02]
[19]
[09]
[07]
[02]
[20]
[18]
[14]
