SANUS VuePoint F80b Montageanleitung Seite 12

2-2
Solid Concrete and Concrete Block Mounting – See Cautions in Step 2.
1
Level wall plate and mark the hole locations.
≥ 211.5 mm
(81⁄3 in.)
3
Insert lag bolt anchors [26].
12
[01]
≥ 211.5 mm
(81⁄3 in.)
[26]
2
Drill pilot holes as illustrated.
4
[25]
[26]
[24]
[01]
Tighten the lag bolts [24] only until the washers
[25] are pulled fi rmly against the wall plate [01].
13mm 13mm
(1/2 in.) (1/2 in.)
63.5 mm
2½ in.
6902-002033 <01>
