Specifications

Model Heating area, sq. m.
Mini 01
Mini Plus 01
Mini 02
Standart 03
Standart Plus 03
Maxi 05
Maxi Plus 05
Standart 07
Standart Plus 07
Voltage range - 210-230 W.
Rated current, 1.1a, 1.7A, 2.2a.
Frequency, 50 Hz.
Metal case: ceramic granite, metal.

Connection Diagram

WARNING! Forbidden to a
serial connect of devices. This will
disable devices and electric
network.
Peculiarities of installation
WARNING! Mount the unit at the same distance
between the floor and the sill or floor at a distance of
8-15 cm.
WARNING! Heaters should be mounted on
concrete, stone or metal surface. In no case do not
install the heater on flammable surfaces.
Necessarily to make sure that the electrical
equipment and electricity grid not damaged. When
installing ensure grounding connection.
The automatic protection and wire cross-section is
chosen according to the number of installed panels
for total capacity.
The panel is mounted on the wall at a height of not
less than 8 cm from the floor to the lamella using
dowels that are in supplied set or other means of
fastening depending on the base.
Using a special legs (sold separately), you can set
the unit on the floor.
EN
18
The volume of heating,
cu. m.
3-5 7.5-12.5
4-6 10-15
3-5 7.5-12.5
7-10 17.5-25
8-12 22-30
13-15 32.5-37.5
14-16 40-50
8-10 20-25
L
220 Â
N
grounding
The size of panels, mm Panel weight, kg
600x400x12
600x400x12
1200x200x12
600x600x12
600x600x12
1000x500x12
1000x500x12
400x900x12
Protection class: IP 44.
Heating temperature: 75 +/- 5 ° C.
Working life: 25 years.
the automatic protection, thermostat, timer
Panel
Precautions
• Reliable attach the heater on the wall and place it in
the correct position.
• The heater should be installed so that a person who
takes a bath or shower, could not accidentally touch
the heating panel.
• The heater should never be placed in the wall outlet.
• When installing wall-mounted version not place the
heater close to the bath, shower or swimming pool.
• If the power cord damage, contact a qualified
electrician or customer service.
• Do not cover the working heater!
• Make sure the heater is completely cooled before
you remove it for storage.
• If the heater does not planned to be used for a long
time, it is recommended to clean and pick up in
storage (preferably in their original packaging) in a
cool dry place.
Power, W
9 270
9 370
9 270
12 370
12 500
16 500
16 750
14 370
Panel Panel
