Dimol Mini 01 Handbuch Seite 17

Thank you for purchasing our appliance, we hope that
the quality of his work will bring you pleasure. Before
using the appliance, please read the instruction
manual. Pay particular attention to the chapter
"Safety", and follow all of the requirements therein.
Proper installation, working and care of the device is
extremely important both for your safety and for the
safety of other people who will use electric heaters.
Complectation
1. Heater - 1 pc.
2. Packaging corrugated cardboard - 1 pc.
3. Wall mounting brackets - 2 pcs.
4. Dowels 6x40 - 4 pcs.
5. Instructions for use and warranty certificate
of the device - 1 pc.
6. Instructions for use intelligent control
(for Series Plus) - 1 pc.
Safety
WARNING! Before using the heater, read the
manual and keep it in an accessible place.
1.1. Wiring safety
• Use a heater only at a voltage of 210-230 V.
• Before connecting the appliance make sure that
electrical equipment and wiring for damage.
• Wiring, which connects equipment must be
grounded. Crossing the wire in a network must
conform electrical power to be connected.
• To connect one panel should use a cable at least
3x0,75 sq.mm.
• Required line voltage 210-230 V, 50-60 Hz frequency.
Check your connection to avtomatic protector.
• Automatic protection should be set based on the
number of panels (1 panel 1,7A).
• Check the electrical panel in the absence of
deformation. If the panel is cracked or broken, you
should contact a specialized service center.
• Wrap, clean and leave radiant panels in the inactive
state over the long term can only be to the exclusion
of the power supply.
1.2. Safety during installation.
WARNING! You can not cover the heater body,
and the more it dry clothes, towels and other things.
• The connection must be carried out only by qualified
experts in accordance with the "Rules of safety and
operation of electrical".
• Not allowed operation of the heater without
avtomatic protection against changes in voltage.
• Not allowed operation of the heater without
grounding.
• If using a ground not proven specialist, you must
install protection device residual current device RCD-
2001 or the like.
EN
16
• Do not connect the heater to the regular power
network without wires reviewing the state a qualified
technician. In disrepair regular power network is
necessary to use a new network for the heaters.
• When using the old power network or unchecked an
expert a network, the manufacturer is not liable for
possible ignition of of network wires or short circuit.
• Do not use this heater with additional devices such
as a timer or any other device that automatically
turns off the unit if the heater is covered or incorrectly
located. Likewise, the device should not be connected
to the chain, which often opens and closes.
• Do not connect the heater to the regular power
network without wires reviewing the state a qualified
technician. In unsuitability regular power network is
necessary to use a new network for the heaters.
• The connection a heater to a network must be made
via the power cord, plug secured to ensure
guaranteed disconnecting the device from the power
supply.
• Do not connect the device to a power source to the
complete assembly.
• When installing in bathrooms, distance from the
heater to bathrooms, showers and washbasins must
be not less than 1 meter.
• The device should be used in an upright position.
• Distance to objects that are heated, should be not
less than 0.5 m.
1.3. Security operation.
• When of exploitation this appliance heats up. To
avoid burns do not touch the hot surface. Turn off the
appliance and let it cool before moving to another
location.
• Do not use the heater to dry clothes.
• Do not touch the power cord hot surfaces.
• Do not insert between the body of panels and the
wall fingers or any other objects.
• Do not immerse the device in liquid, ensure that the
liquid did not get inside.
• In case of falling into the water immediately turn off
the appliance.
• Do not operate the heater with a damaged cord,
plug. In case of failure, fall or any other damage,
contact a qualified electrician to check the electrical
and mechanical setup, maintenance or repair heater.
• Do not touch the heater working with wet hands.
• To remove dust from the surface, disconnect the
device from the network.
• When cleaning the the device, do not use abrasive
cleaners. Clean with a damp cloth (not wet)
moistened with warm soapy water. Always unplug the
unit before cleaning.
• Before moving electric appliances switch it off and
let it cool down.
• Do not use the appliance with twisted cord, it can
lead to overheating.
• Do not use extension cord.
