Control panel

Figure 2. Description of the control panel
Legend Button
1.
2.
3.
+
4.
-
5.
6.
7.
8.
9.
LED
indicator
8 • EN
Description
POWER: Press to switch monitor on/off.
MODE Press to select input signal.
Note: When pressed initially, the OSD of the current signal
is displayed. Before it disappears, press again to change the
mode.
AUTO: Press to auto adjust VGA signal.
PLUS: Press to increase the value of the OSD option
selected; Press to increase volume.
MINUS: Press to decrease the value of the OSD option
selected; Press to decrease volume.
UP: Press to scroll up OSD option list; Press to adjust
contrast.
DOWN: Press to scroll down OSD option list; Press to adjust
brightness.
MENU: Recall or close OSD display, enter option selection.
Green: Power on; Orange: No signal; Red: Power saving;
NA: Power off
UltraView Color TFT LCD monitor 26 in./ 32 in./ 42 in.
