Flashing green LED:
Self stroking mode = RESET MODE
(period is every second)
Constant green LED:
Positioning mode
Flashing green LED:
Setpoint is reached (period is every
6 seconds)
Flashing red LED: STAND BY mode
(period is every two seconds)
Grüne LED blinkt: automatische
Hubanpassung (Intervall = jede
Sekunde)
Dauerhaft grün leuchtende LED:
Positionierungsmodus
Grüne LED blinkt: Sollwertposition
erreicht (Intervall = alle 6 Sekunden)
Rote LED blinkt: STAND BY Modus
(Intervall = alle 2 Sekunden)
VI.LF.E3.5B
①
③
3-6 sec = STAND BY−ON
STAND BY−OFF
②
LED: red
④
⑤
❹
①
STAND BY, RESET and LOCK MODE on actuator AME 445
Starting from NORMAL MODE
Starting from LOCK MODE
STAND BY, RESET und LOCK-MODUS auf Stellantrieb AME 445
Start aus dem NORMAL-MODUS
Start aus dem LOCK-MODUS
6-9 sec = RESET
LED: green
