Fit the fastening frame and the CoolAir SP950 parking cooler on the Scania
Highline/Topline as follows:
➤ Bolt the condenser unit to the mounting frame with the M8 x 30 hexagon
bolts, M8 8.4 x 16 mm U-washers and M8 retaining nuts (fig. 1, page 3).
➤ Remove the existing screws (fig. 2 1, page 4).
I
NOTE
Make sure the long side (fig. 2 A, page 4) of the spacer is point-
ing towards the rear wall of the truck.
➤ Fasten the spacer (fig. 2 2, page 4) in place of the removed screw using
the M8 x 25 ribbed bolt (fig. 2 3, page 4).
➤ Remove the existing nuts (fig. 2 6, page 4).
➤ Install the mounting frame using the fastening material provided:
– Attach at the top with the M8 (fig. 2 6, page 4) serrated lock nuts
– Attach to the spacer you installed earlier with retaining nut M8
(fig. 2 4, page 4) and bolt M8 x 16 (fig. 2 5, page 4)
➤ Check that all bolts are still tight after travelling approximately 200 km.
7 Guarantee
The statutory warranty period applies. If the product is defective, please
contact the service partner in your country (addresses on the back on the
instruction manual).
Our experts will be happy to help you and will discuss the warranty process
with you in more detail.
