Child car 13-
seat
14-
ISOFIX arm 15-
16-
17-
Support- 18-
leg
5
Adjusting the seat unit's orientation:
Pull and hold the seat rotate adjustment lever (a) then rotate the
seat (b).
Seat positions:
B, C: Sideward facing position:
The sideward facing position allow access for placing or removing a
child from the seat unit after the car seat is fitted.
WARNING: Do Not travel with the seat unit in this position.
D: Rearward facing position:
IMPORTANT: DO NOT USE FORWARD FACING BEFORE THE
CHILD'S WEIGHT EXCEEDS 9 KG.
When use as a rearward facing child car seat, it is suitable for
transportation in cars of children from birth up to maximum weight
of 18 kg.
A: Forward facing position:
When use as a forward facing child car seat, it is suitable for
transportation in cars of children from 9 kg up to maximum weight
of 36 kg.
Location:
The two ISOFIX low anchorage anchor points are usually located
between the vehicle seat base and back (a).
Some vehicles have ISOFIX indicator near the ISOFIX low
anchorage anchor points (b).
Fitting the ISOFIX guides (Optional):
The ISOFIX guides can help identify the vehicle ISOFIX anchor
points and make installation easier. They can also help with the
protection of your vehicle seat.
Fitting:
Press and hold ISOFIX arm adjustment buttons and extended the
arms fully (a).
Engage the ISOFIX arms (b) and ensure that the ISOFIX arm
security indicators are green (c).
Push the base back until it rests firmly against the vehicle seat
backrest (d).
Removal is a reversal of this procedure.
Fitting:
Open the support-leg fully (a).
Adjust the support-leg (b) until it makes firm contact with vehicle
floor (c) and the support-leg contact indicator is green (d).
