Rearward facing modes (Group 0/ 0+/1) (up to 18kg, approx. 4
years old)
19- Location:
Cosatto recommend to use the car seat in rearward facing mode for
as long as possible.
IMPORTANT: Never use the child car seat on a seat where an airbag
is fitted and active. Refer to your vehicle user manual for information
on de-activating the airbag.
ISOFIX option (fitted with ISOFIX low anchorage points and
support-leg) (Group 0/1, 0-18kg):
20- Fitting:
Convert the seat unit to rearward facing orientation (refer to step
13).
Recline the backrest to position R (refer to step 1) (a).
Position the child car seat on the vehicle seat, rearward facing.
Attach the ISOFIX arms to the anchor points (refer to step 14 - 16) (b).
Engage the support-leg (Refer to step 18).
Removal is a reversal of this procedure.
Belted with support-leg (Group 0+, 0-13kg):
Fitting:
21-
Convert the seat unit to rearward facing orientation (refer to step 13).
Recline the backrest to position R (refer to step 1).
Position the child car seat on the vehicle seat, rearward facing.
Open the harness (refer to step 8) and lift up the lower seat liner (a).
Pull the vehicle belt over the child car seat (b) and fasten the vehicle
belt buckle (c).
The lap vehicle belt should position below the waist harness (d).
Tension the lap vehicle belt (e).
Pull the diagonal vehicle belt over the child car seat backrest (f,g).
22-
Tension the diagonal vehicle belt (a & b).
If fitted correctly the vehicle belt should cover the belt guide
markings on the child seat cover (c & d).
IMPORTANT: The position of the vehicle belt buckle can affect the
stability of the child restraint system. In an accident this could stop
the child restraint system from protecting your child as well as it
should. After tightening the vehicle belt, if the buckle lies in the
position marked (X) then try fitting the child restraint system in
another seating position in your vehicle.
Engage the support-leg (Refer to step 18).
Removal is a reversal of this procedure.
