Danfoss InterBus-S Handbuch Seite 21

FEN3 : KF +200
AV : KF +1
RRST : DB 23
CIST : DB 21
RRMW: KF +20
CIMW : KF +22
CIFB : FY 63
T : T 0
STEP : FY 9
BUSY : F 8.0
TO : F 8.1
RET : F 8.2
:A F 8.0
:ON F 8.2
:JC =M001
:STS
:BEU
M001 :JU FB 62
NAME :CON/IND
IBDB : DB 9
CIDB : FY 18
T : T 1
TO : F 8.3
:
:
:L KF +8
:T FY 100
:L KF +25
:T FY 101
:L KF +0
:T FY 102
:AN F 8.0
:A F 10.0
:JC FB 69
NAME :DEFINE
IBDB : DB 9
T : T 5
FKT : FY 100
DB : FY 101
DW : FY 102
BUSY : F 103.0
TO : F 103.1
MG.10.G1.51 – VLT is a registered Danfoss trademark
Gateway InterBus-S
Basic address: Window 3
Controlled operation / report released
REQ/RES Standard DB
CON/IND Standard DB
Activation word
Report word
Auxiliary driver CON/IND
Timer
Internal flag byte
Activation bit
Time Out
Return value
InterBus Data block
Caption-DB-CON/IND
Timer
Time Out
**** Change PDU length ********
change in CRL, here only !!!
Function 8
DB-Number is 25
upwards of DW 1
No BUSY-Signal from FB60
Pseudo-cycle
DEFINE from IBS
InterBus DB
Timer No.5
Function (8) Receive CRL
DB-Number
upwards of DW
21
