Danfoss InterBus-S Handbuch Seite 20

PKER : FW 214
PARR : FW 216
PCPR : F 200.3
ERR : F 200.6
OK : F 200.7
:
:O F 200.6
:R F 200.5
:
:A F 200.7
:A F 224.1
:JC FB 2
NAME :PARAMETE
PDB : DB 100
COUN : FW 220
ANZA : KF +17
PKEW : FW 210
PARW : FW 212
OK : F 200.7
STRT : F 200.5
ZEIG : FW 222
INIT : F 224.0
:
:JU FB 66
NAME :REQ/RES
IBDB : DB 9
RRDB : FY 19
T : T 3
TO : F 8.4
:BE
FB 210 FB 210
FB 210 FB 210 FB 210
NAME :ANLAUF
:A F 8.0
:ON F 8.0
:S F 8.0
:S F 10.0
:L KY 20,22
:T FW 18
M002 :A F 8.0
:JC FB 60
NAME :ANLAUF
IBDB : DB 9
20
Gateway InterBus-S
PCA from the VLT
Parameter value from the VLT
;If error, reverse activation
;OK-report from FB1
;Activation for Download
DB with Download data
Parameter counter
Number of parameters
PCA to the VLT
Parameter value to the VLT
OK-report from FB1
Start for FB1
Parameter indicator
Download initialized
InterBus Data block
REQ/RES caption table
Timer
Time Out
Activation bit: INITIB
ADDRESS
CON/IND,REQ/RES
DB PCP caption tables
InterBus Data block
MG.10.G1.51 – VLT is a registered Danfoss trademark
