Programmlaufdiagramm

LiPo BALANCE CHG
BATT/PROGRAM
2.0A 7.4V (2S)
LiPo BATT
ENTER
LiFe BALANCE CHG
BATT/PROGRAM
2.0A 6.6V (2S)
LiFe BATT
ENTER
Lilo BALANCE CHG
BATT/PROGRAM
2.0A 7.2V (2S)
LiIo BATT
ENTER
LiHV BALANCE CHG
BATT/PROGRAM
2.0A 7.6V (2S)
LiHV BATT
ENTER
BATT/PROGRAM NiMH CHARGE
NiMH BATT CURRENT 2.0A
ENTER
BATT/PROGRAM NiCd CHARGE
NiCd BATT CURRENT 2.0A
ENTER
Pb NORMAL CHG
BATT/PROGRAM
2.0A 2.0V (1P)
Pb BATT
ENTER
BATT/PROGRAM 4.20 4.19 4.19 V
BATT METER 0.00 0.00 0.00 V
ENTER
BATT/PROGRAM 5 3
BATT RESISTANCE 5 0
ENTER
BATT/PROGRAM Safety Timer
SYSTEM SETTING-> ON
ENTER
Stop
Version
HW:1.00 FW: 1.00
BATT PROG
[ BATT MEMORY 1 ]
BATT/PROGRAM
ENTER SET->
BATT MEMORY
ENTER
ENTER CHARGER
LOAD......
[ BATT MEMORY 2 ]
ENTER SET->
ENTER
[ BATT MEMORY 2 ]
C:1.0A D:1.0A
ENTER CHARGER
LOAD......
[ BATT MEMORY 3 ]
ENTER SET->
ENTER
Pb NORMAL CHG
2.0A 2.0V (1P)
Pb AGM CHG
0.1A 2.0V (1P)
· 08
LiPo CHARGE
2.0A 7.4V (2S)
LiFe CHARGE
2.0A 6.6V (2S)
Lilo CHARGE
2.0A 7.2V (2S)
LiHV CHARGE
2.0A 7.6V (2S)
NiMH Auto CHARGE
CURRENT 2.0A
NiCd Auto CHARGE
CURRENT 2.0A
Pb AGM CHG
0.1A 2.0V (1P)
MAIN 12.58V
H4.20V L4.19V
3 mΩ TATAL: 16mΩ
0 mΩ
Capacity Cut-Off
120Min ON 5000mAH
Load Factory Set
Enter
BATT TYPE
LiPo
ENTER
[ BATT MEMORY 1 ]
ENTER>3 Seconds
C:4.9A D:2.2A
LiPo BALANCE CHG
4.9A 7.4V(2S)
BATT TYPE
NiMH
ENTER
[ BATT MEMORY 2 ]
NiMH 2.4V (2S )
NiMH CHARGE
CURRENT 1.0A
BATT TYPE
Pb
ENTER
ENTER CHARGER
LOAD......
ENTER>3 Seconds
INC Pb COLD CHG
0.1A 2.0V (1P)
DEC
LiPo FAST CHG LiPo STORAGE
2.0A 7.4V (2S) 2.0A 7.4V (2S)
LiFe FAST CHG LiFe STORAGE
2.0A 6.6V (2S) 2.0A 6.6V (2S)
Lilo FAST CHG Lilo STORAGE
2.0A 7.2V (2S) 2.0A 7.2V (2S)
LiHV FAST CHG LiHV STORAGE
2.0A 7.6V (2S) 2.0A 7.6V (2S)
NiMH DISCHARGE NiMH RE-PEAK
0.1A CUT: 1.0V
NiCd DISCHARGE NiCd RE-PEAK
0.1A CUT: 1.0V
Pb COLD CHG Pb DISCHARGE
0.1A 2.0V (1P) 0.1A 2.0V (1P)
Temp Cut-Off Temperature Unit
ON 50°C 122°F Celsius
DC Input Low Key Beep
Cut-Off 11.0V Buzzer
BATT VOLTAGE
CHARGE CURRENT
7.4V ( 2S )
[ BATT MEMORY 1 ]
SAVE PROGRAM
LiPo 7.4V (2S )
SAVE....
LiPo CHARGE LiPo FAST CHG
4.9A 7.4V(2S) 4.9A 7.4V(2S)
BATT VOLTAGE
CHARGE CURRENT
2.4V (2S)
SAVE PROGRAM SAVE PROGRAM
SAVE.... ENTER
ENTER
NiMH Auto CHARGE NiMH DISCHARGE
CURRENT 1.2A 1.0A CUT: 2.0V
BATT VOLTAGE
CHARGE CURRENT
4.0V (2P)
[ BATT MEMORY 3 ]
[ BATT MEMORY 3 ]
Pb 4.0V (2S )
C:3.3A D:1.5A
Pb DISCHARGE
1.5A 4.0V(2P)
LiPo DISCHARGE
2.0A 7.4V (2S)
LiFe DISCHARGE
2.0A 6.6V (2S)
Lilo DISCHARGE
2.0A 7.2V (2S)
LiHV DISCHARGE
2.0A 7.6V (2S)
NiMH CYCLE
1 CHG>DCHG 1
NiCd CYCLE
1 CHG>DCHG 1
Rest Time
CHG>DCHG 10Min
ON NiCd Sensitivity
ON D.Peak 4mV
DISCHG CURRENT
4.9A 2.2A
SAVE PROGRAM
ENTER
ENTER
LiPo STORAGE
4.9A 7.4V(2S)
TRICKLE
3.3A 100mA
DISCHG VOLTAGE
1.1V/CELL
NiMH RE-PEAK
2
DISCHG CURRENT
3.3A 1.5A
SAVE PROGRAM
SAVE PROGRAM
SAVE....
ENTER
NiMH Sensitivity
D.Peak 4mV
DISCHG VOLTAGE
3.0V/CELL
TVC=YOUR RISK
4.20V
LiPo DISCHARGE
2.2A 7.4V(2S)
PEAK DELAY
1Min
DISCHG CURRENT
2.2A
NiMH CYCLE
DCHG>CHG 1
DISCHG VOLTAGE
1.7V/CELL
ENTER
