Usage of the MicroModules in a 3 phase installation.
The X10 transmitters of the MicroModules transmit the command
only once for use in the phase of which they are connected. When
you want to receive the commands on your other phases as well, you
will need to install the CAT3000 phase coupler/repeater.
Technical specifications
Power
Supply current
Appliance module
Signal transmission
X10 transmission
Signal sensitivity
Signal to Noise ratio
Connections
Approvals
Made in Holland
10
230V, 50Hz
< 30 mA capacitive
16 A
> 5Vpp in 5Ohm at 120 kHz ±1 kHz
according to EN50065-1, EN50065-2-1,
EN50065-4-1
1 pulse burst at 0° and 180°
25mVpp ... 6Vpp at 120 kHz ± 4kHz
1,35 : 1
2
up to 2,5 mm
NEN-EN-IEC 60669-2-1 and
NEN-EN-IEC 60669-2-2
MARMITEK
