DESCRIPTION OF THE DEVICE

4 5 6 7
16 17 18 19 20
8 9 10 11 12 13
24
21 22 23
(1) Projector head
1
(2) LED/lens
2 (3) Yoke
(4) Wireless indicator
3 (5) Ethernet indicator
(6) Mounting plate/safety hole
(7) LCD
(8) Microphone
(9) ESDC switch
(10) Arrow button left
(11) Arrow button down
(12) Enter button
(13) Arrow button up
(14) Arrow button right
(15) Base
14 15
(16) Carrying handle
25
(17) Network/Ethernet connector
(18) 5-pin DMX input socket
(19) 5-pin DMX output socket
(20) Network/Ethernet connector
(21) Power input
(22) Power output
(23) Fuse holder
(24) Rubber foot
(25) Fan
26
(26) Power switch
