Icom Ic275, Ic725, Ic726, Ic728, Ic729, Ic735, Ic736, Ic737, Ic738, Ic746Pro, Ic756Proiii, Ic761, Ic765, Ic775, Ic781, Ic820, Ic821, Ic910, Ic970, Ic7400, Ic7600, Ic7700, Ic7800 - RF System TinyGate Benutzerhandbuch

TinyGate – Bauanleitung und Benutzerhandbuch
Icom IC275, IC725, IC726, IC728, IC729, IC735,
IC736, IC737, IC738, IC746PRO, IC756PROIII,
IC761, IC765, IC775, IC781, IC820, IC821, IC910,
IC970, IC7400, IC7600, IC7700, IC7800
Pinbelegung Transceiverkabel (X2 <-> Transceiver ACC1-Buchse):
Pin JP1-Bruecke zu Signal
X2
1
2
3
4
5
6
7
8
S e i t e 29
GND
MIC
GND
PTT
SPK
COR/SQL
PWR
Aderfarben Pin an ACC(1)
2
4
2
3
5
6
7
