Installation and commissioning

General

NOTE!
The following steps are described using the RC Panel Basic as an example, however
the process is the same on all variants of the RC Panel.

Fitting options

Risk of injury and material damage from falling remote control.
► Always secure the remote control to prevent it from falling down.
Fitting to a bar:
*
Connecting the
1
1
remote control to
system compo-
nents
SpeedNet connection socket
CAUTION!
*
Cable not provided with RC Panel Basic /BT
Fitting to a hook:
*
1
1
TMC connection socket
37
