CD2 – CD3 – CD6
TECHNICAL SPECIFICATIONS (CONTINUED)

APPLICABLE FOR 10.5 BAR UNITS ONLY

Nominal conditions
Compressed air inlet pressure (e)
Limit values
Maximum compressed air inlet pressure (e)
Minimum compressed air inlet pressure (e)
Specific data
Nominal capacity at dryer inlet
Purge air consumption (average during 1/2 cycle)
Time of half a cycle
Purge time
Pressure drop through dryer
In- and outlet connection
Total amount of desiccant
Recommended filter size
Power consumption
Mass
Desiccant type
Detailed dimensions
Correction factors
Inlet pressure (bar)
Correction factor Kp
Temperature (°C)
Correction factor Kt
8
CD2
7 bar
10.5 bar
4 bar
1.4 l/s
20 %
120 s
120 s
19 mbar
1/4 "
0.5 kg
PD/DD 6
3 W
5.4 kg
4 5 6
0.63 0.75 0.88
20 25 30
1 1 1
CD3
7 bar
10.5 bar
4 bar
2.8 l/s
20 %
120 s
120 s
75 mbar
1/4 "
0.9 kg
PD/DD 6
3 W
6.5 kg
Activated Aluminium AL2O3
Refer to figure 6a.
7 8 9
1 1.13 1.25
35 40 45
1 0.97 0.88
CD6
7 bar
10.5 bar
4 bar
6.1 l/s
20 %
120 s
120 s
300 mbar
1/4 "
1.7 kg
PD/DD 6
3 W
9.2 kg
10
1.38
50
0.73
2904 0104 02
