Herth+Buss Reanimator Surge Bedienungsanleitung Seite 23

Operating Instruction
7. Press the ON/OFF button again, hold it
down until the LED control lamp "BYPASS"
starts to flash green and then release
the button once more. The LED flashes
for as long as the bypass mode is being
initialised and then lights up continuously
once the device has switched to bypass
mode.
9. Switch on the ignition and start the engine.
10. Repeat the process if the engine does not
start up immediately. Please observe the
necessary cooling phases in the process.
11. Connect the battery pole clamp to the
positive battery pole again once the en-
gine has started and tighten it again im-
mediately.
12. Switch the assisted start device off and
disconnect it.
NOTE
The GLOW mode is disabled in bypass
mode and cannot be activated.
After 2 minutes, the device automatically
switches to idle mode if no starting process
has been initiated. The battery voltage
continues to be displayed in the meantime
23
95980800
EN
