tions given in this operating manual and that
have been tested and marked in accordance
with EN 847­1.
SAFETY WARNINGS FOR BATTERY
a) Do not open the battery. Danger of shortcircuiting.
b) Protect the battery against heat, e. g., against
continuous intense sunlight, fire, water, and
moisture. Danger of explosion.
c) In case of damage and improper use of the bat­
tery, vapours may be emitted. Ventilate the area
and seek medical help in case of complaints.
The vapours can irritate the respiratory system.
d) Use the battery only in conjunction with your
Vonroc product. This measure alone protects
the battery against dangerous overload.
e) The battery can be damaged by pointed objects
such as nails or screwdrivers or by force applied
externally. An internal short circuit can occur and
the battery can burn, smoke, explode or overheat.
SAFETY WARNINGS FOR CHARGER
Intended use
Charge only CD801AA and CD803AA type rechar-
geable Battery packs with the charger. Other types
of batteries may burst causing personal injury and
damage.
a) The appliance is not to be used by persons
(including children) with reduced physical, sen­
sory or mental capabilities, or lack of experien­
ce and knowledge, unless they have been given
supervision or instruction.
b) Children being supervised not to play with the
appliance.
c) Do not recharging non­rechargeable batteries!
d) During charging, batteries must be placed in
the well ventilated area!

2. MACHINE INFORMATION

Intended use
This cordless circular saw is intended for length-
wise, crosswise and bevel cutting in wood while
keeping the baseplate resting firmly on the work-
piece. Sawing plastics or metals is not permitted.
The power tool with the fitted sawblade is designed
with sufficient capacity for sawing hardwood and
softwood as well as chipboard and fibreboard. The
sawblade is not designed for cutting firewood. Do
not use the saw to cut materials other than those
specified described in manual.
WWW.VONROC.COM

TECHNICAL SPECIFICATIONS

Model No.
Voltage
No load speed
Saw blade size
Sawing capacity 0°
Sawing capacity 45°
Weight
Sound pressure level L
PA
Sound power level L
WA
Vibration
Model No
Battery Type
Voltage
Capacity
Recommended charger
Weight
Model No
Charger input
Charger output
Charging time 2Ah battery
Charging time 4Ah battery
Recommended batteries
Weight
Only use the following batteries of the VONROC
POWER 20V battery platform. Using any other
batteries could cause serious injury or damage the
tool.
CD801AA 20V, 2Ah Lithium-Ion
CD803AA 20V, 4Ah Lithium-Ion
The following charger of the can be used to charge
these batteries.
CD802AA Quick charger
The batteries of the VONROC POWER 20V battery
platform are interchangeable with all the VONROC
POWER 20V battery platform tools.
EN
S_CS501DC
20V
4000 /min
Ø150×Ø16×1.6mm
48mm
36mm
2.1 kg
75.3 dB(A), K=3dB(A)
86.3 dB(A), K=3dB(A)
3.015 m/s K=1.5 m/s
2 2
CD801AA
Lithium-Ion
20V
2.0 Ah
CD802AA
0.3 kg
CD802AA
220-240V,50Hz 0.4A
21V 2.5A
60 minutes
120 minutes
CD801AA, CD803AA
0.36 kg
