8 - Ethernet
A.
Make an incision on the
M25 3-exit grommet. Cut
the thin plastic area. Insert
the M25 3-exit grommet.
B.
Insert the ethernet cable
only, crimp the RJ45
connector to the cable and
connect it to the ethernet
port.
Inserting the cable with the RJ45
connector through the grommet
will void the warranty.
C.
Close the communication
lid.
T10
