not actually being used should also be taken into account.
This may significantly reduce vibration and noise emissions
over the total working period.
Implement additional safety measures to protect the oper-
ator from the effects of vibration, such as servicing the
power tool and application tools, keeping their hands warm,
and organising workflows correctly.
Assembly
Remove the battery from the power tool before carry-
u
ing out work on the power tool (e.g. maintenance,
changing tool, etc.). The battery should also be re-
moved for transport and storage. There is risk of injury
from unintentionally pressing the on/off switch.

Battery charging

Use only the chargers listed in the technical data. Only
u
these chargers are matched to the lithium-ion battery of
your power tool.
Note: The battery is supplied partially charged. To ensure
full battery capacity, fully charge the battery in the charger
before using your power tool for the first time.
The lithium-ion battery can be charged at any time without
reducing its service life. Interrupting the charging process
does not damage the battery.
The lithium-ion battery is protected against deep discharge
by the "Electronic Cell Protection (ECP)". When the battery
is discharged, the power tool is switched off by means of a
protective circuit: The application tool no longer rotates.
Do not continue to press the On/Off switch after the
u
power tool has automatically switched off. The battery
can be damaged.
Removing the battery
To remove the battery (6), press the release button (5) and
pull the battery back and out of the power tool. Do not use
force to do this.
Battery charge indicator
When the on/off switch (10) is pressed in halfway or com-
pletely, the battery charge-control indicator (8) indicates
the charge condition of the battery for several seconds. The
indicator consists of three green LEDs.
LED
Continuous lighting 3 x green
Continuous lighting 2 x green
Continuous lighting 1 x green
Bosch Power Tools
LED
Slowly flashing light 1 x green
The three LEDs in the battery charge indicator flash
quickly when the temperature of the battery is outside
the operating temperature range of –30 to +65 °C and/or
the overload protection has been triggered.

Changing the Tool

Remove the battery from the power tool before carry-
u
ing out work on the power tool (e.g. maintenance,
changing tool, etc.). The battery should also be re-
moved for transport and storage. There is risk of injury
from unintentionally pressing the on/off switch.
Inserting the application tool (see figure A)
Insert the application tool all the way into the holder (1).
Fitting the adapter (see figure B)
Remove the application tool.
Insert the adapter into the holder (1). The adapter clicks
audibly into place.
Inserting the application tool into the adapter (see figure
C and D)
Insert the application tool all the way into the holder (1). The
application tool is held in the holder by means of a magnet.
Drill chuck adapter (see figure E)
Open the drill chuck adapter (11) by turning it in the direc-
tion of rotation ➊ until the application tool can be inserted.
Insert the application tool.
Firmly tighten the sleeve of the drill chuck adapter (11) by
turning it by hand in the direction of rotation ➋. This will
automatically lock the drill chuck.
Turning the adapter (see figure F)
Remove the adapter from the power tool. Turn the adapter
to the required position and then reattach it.
Removing the adapter (see figure G)
Remove the application tool.
Pull the adapter off the mounting (1).
Combining adapters (see figure H)
Insert the angle screw adapter (13) into the mounting (1).
Then insert the drill chuck adapter (11) into the angle screw
adapter (13).

Dust/Chip Extraction

Dust from materials such as lead-containing coatings, some
wood types, minerals and metal can be harmful to one's
health. Touching or breathing-in the dust can cause allergic
reactions and/or lead to respiratory infections of the user or
bystanders.
Certain dust, such as oak or beech dust, is considered carci-
Capacity
nogenic, especially in connection with wood-treatment ad-
ditives (chromate, wood preservative). Materials containing
≥ 66%
asbestos may only be worked by specialists.
33–66%
– Provide for good ventilation of the working place.
11–33%
English | 19
Capacity
≤ 10%
