Figure A.1
AC Power
Cord
Signal
Cable
1. Cables pass through in this hole.
2. Connect each connector.
3. Replace connector cover with
cables passing through upper
opening.
Power Outlet
01b_English
15-pin
mini D-SUB
Mac Adapter
(not included)
To Computer
English-4
4
Figure B.1
Figure C.1
INPUT2 AC-IN
INPUT1
Power Switch
Figure D.1
13.12.2000, 11:50 Uhr
15-pin
mini D-SUB
