Controls
OSM (On-Screen-Manager) Controls
The OSM controls on the front of the monitor function as follows:
To access OSM press any of the control buttons ( , , , ).
To change signal input, press the INPUT 1/2 button.
Control
EXIT
CONTROL /
CONTROL /
PROCEED
RESET
NOTE: When RESET is pressed in the main and sub-menu, a warning
window will appear allowing you to cancel the RESET function
by pressing the EXIT button.
Brightness/Contrast Controls
01b_English
Main Menu
Exits the OSM controls.
Moves the highlighted
area up/down to select
one of the controls.
Moves the highlighted
area left/right to select
control menus.
Has no function.
Push PROCEED to
activate Auto Adjust.
Resets the highlighted
control menu to the
factory setting.
BRIGHTNESS
Adjusts the overall image and background screen
brightness.
CONTRAST
Adjusts the image brightness in relation to the
background.

AUTO ADJUST

Adjusts the image displayed for non-standard video
inputs.
English-7
7
Sub-Menu
Exits to the OSM controls
main menu.
Moves the highlighted area
up/down to select one of the
controls.
Moves the bar left/right to
increase or decrease the
adjustment.
Activates Auto Adjust feature.
In Tools and Information
Mode, opens additional
window.
Resets the highlighted control
to the factory setting.
