Nemo D4-Dc
1.5 RS485 ModBus RTU communication
N° Address: 1...255
increases the loaded value
↵
moves the cursor
confirms
Baud rate: 4800 – 9600 – 19200 bits/second
↵
selects the value
confirms
Parity bit: none – even – odd
nonE none EVEn even
↵
selects the value
confirms
Time-out: 3...100ms
increases the loaded value
↵
moves the cursor
confirms
8
odd odd
1.6 Alarms
Alarms 1
Associated quantity:
CUrr current VOLt voltage
↵
selects quantity
confirms
Polarity:
POS positive nEg negative
↵
selects polarity
confirms
Decimal point: 000.0 - 00.00 - 0.000
↵
selects the position of the decimal point
confirms
Engineering unit: A/kA (current) - V/kV (voltage) - kW/MW (power)
↵
selects the engineering unit
confirms
POUr power PMd power demand
