2. Push the staples or the T-nails into the maga-
zine .
5
CAUTION! Ensure that the staples or T-nails
are correctly inserted (see Figs. B, C, D).
3. Push the staple pusher
zine . Press in the staple pusher
5
and then pull it slightly upwards to fix it in place.

Setting the impact force

CAUTION! Never screw the adjusing screw
completely out of the stapler gun. This could
result in damage to the device.
Screw out the adjusing screw
the impact force.
Screw in the adjusing screw
the impact force.
Stapling
CAUTION! Never support yourself by placing
your hands near or in front of the stapler gun
or the workpiece surface. A slip can result in
injury.
Follow these steps:
1. Press the staple eject opening
where you wish to staple.
2. Adjust the impact force to suit the materials,
staples or nails.
3. Press the operating lever
Examples of use:
The stapler gun is suitable for the following purposes:
- Attaching coverings to the seating surface of
chairs.
- Attaching a skirting at the joint between wall
and floor coverings.
- Stretching and stapling canvasses to frames.
- Attaching protective films to insulation materials
when installing thermal insulation.
- Attaching decorative materials.
back into the maga-
3
slightly
3
1
to reduce
1
to increase
1
on the spot
7
down firmly.
2
Removing staples
To avoid the risk of injury!
Ensure that the operating handle
pressed.
Push the hook under the staple or nail head
4
(see Fig. F).
Pull the rear part of the stapler gun upwards to
draw out the staple or nail from the workpiece.
R emoving jammed staples
from the stapler gun
Staples or nails may become jammed in the stapler
gun during operation. Remove jammed staples as
follows:
1. Press in the staple pusher
pull it downwards. Then pull the staple pusher
completely out of the magazine
2. Turn the stapler gun over so that the magazine
is pointing upwards.
5
3. Press the magazine
backwards and pull the magazine
(see Fig. E).
4. Now remove the jammed staples from the
magazine .
5
5. Press the magazine
backwards and press it downwards until it en-
gages to fix the magazine
Note: Do not use the stapler gun if it shows more
serious defects (damage to body etc.). If necessary
have your stapler repaired by a qualified specialist.
Take note that the manufacturer's original spare parts
only should be used in any repair.
Tips
1. In order to have a good quality of stapling, it is
suggested to fill only one of staple / nail type in
the staple gun in each time.
2. When you want to change other types of sta-
ples, please make sure all remaining staples /
nails are used up or not in staple gun before
insert other types of staples / nails.
Operation
will not be
2
slightly and then
3
.
5
at the side wings
5 6
upwards
5
at the side wings
5 6
back in place.
5
