• 1 x COM Port Header
• 1 x Power LED Header
• 1 x TPM Header
• 1 x CPU Fan Connector (4-pin)
• 1 x Chassis Fan Connector (4-pin)
• 1 x SATA Power Connector
• 1 x Internal Power Header
• 1 x Front Panel Audio Connector
• 1 x Analog Surround Audio Connector
• 3 x USB 2.0 Headers (Support 5 USB 2.0 ports) (Supports ESD
• 1 x USB 3.0 Header by Etron EJ188 (Supports 2 USB 3.0 ports)
• 64Mb AMI UEFI Legal BIOS with GUI support
BIOS
• Supports Plug and Play
Feature
• ACPI 1.1 compliant wake up events
• Supports jumperfree
• SMBIOS 2.3.1 support
• CPU/Chassis temperature sensing
Hardware
• CPU/Chassis Fan Tachometer
Monitor
• CPU/Chassis Quiet Fan (Auto adjust chassis fan speed by
• CPU/Chassis Fan multi-speed control
• Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore
• Microsoft® Windows® 10 64-bit / 8.1 64-bit / 7 64-bit
OS
* To install Windows® 7 64-bit OS, a modified installation disk
with xHCI drivers packed into the ISO file is required. Please
refer to page 166 for more detailed instructions.
* For the updated Windows® 10 driver, please visit ASRock's
website for details: http://www.asrock.com
• FCC, CE, WHQL
Certifica-
• ErP/EuP ready (ErP/EuP ready power supply is required)
tions
* For detailed product information, please visit our website: http://www.asrock.com
Due to limitation, the actual memory size may be less than 4GB for the reservation
for system usage under Windows® 32-bit operating systems. Windows® 64-bit operat-
ing systems do not have such limitations. You can use ASRock XFast RAM to utilize
the memory that Windows® cannot use.
Protection (ASRock Full Spike Protection))
(Supports ESD Protection (ASRock Full Spike Protection))
CPU temperature)
N3150TM-ITX
