Belt installation
• Position the seat on the vehicle seat. Make sure the carrying handle is up in the carrying
position (5).
• Guide the hip belt of the 3-point-belt over the blue sections under the hip belt hooks and
fasten the seat belt with a ' c lick' (6).
• Guide the shoulder belt over the blue section through the shoulder belt hook at the rear
side of the seat shell (7).
• Tighten the 3-point belt by pulling the belt through the hip belt hooks and through the
shoulder belt hook until it is as tight as possible (8).
• Leave the carrying handle up in carrying position.
Positioning of the child
• Check that the shoulder strap slots are level with your child's shoulders (9).
• Pull the shoulder straps up while pressing the button of the central adjuster (10).
• Open the harness buckle (11).
• The height of the shoulder straps and the head cushion can be adjusted by pulling the
release handle upwards at the back of the seat and pulling the handle up or down (12).
• Position the shoulder straps over the marking at the sides of the seat to use the magnets
to keep the harness open while you position the child (13).
• When the child is positioned, place the shoulder straps over the child's shoulders and
close the buckle: CLICK! (14).
• Pull the harness strap through the central adjuster in the direction of the arrow straight
up/forwards. Continue pulling until the harness is a comfortable but a firm fit (15).
• You can protect your child against the sun by raising the sun canopy.
Baby cushion
The baby cushion offers extra comfort for young babies. As baby grows the thickness of the
baby cushions can be adjusted.
• 0-4 m (16).
• 4-6 m (17).
• 6 m + (18).
