Preparing to install
• Carrying handle (1a)
• Head cushion (1b)
• Head space reducer (1c)
• Handle release buttons, 2x (1d)
• Shoulder straps, 2x (1e)
• Hip belt hook, 2x (1f)
• Baby cushion (1g)
• Harness buckle (1h)
• Sun canopy (1i)
• Stroller release handles, 2x (1j)
• Shoulder belt hook (1k)
• Harness height adjuster (1l)
• Stroller adapter house (1m)
Installation of the seat on the i-Size base
• Check if the ISOfix and floor support indicators on the base are green (2).
• Position the seat in the correct position on the base untill it clicks with the base and the
indicator at the front shows green (3).
• Leave the carrying handle up in the carrying position.
• When the seat is positioned rearfacing on the back seat of the vehicle, you should, if
possible, push the front seat of the vehicle backwards, so that it is in contact with the child
seat. If it is not possible to obtain contact with the child seat, push the back rest of the
front seat of the vehicle forward as far as possible (4).
• The seat is delivered with removable SIP+ (side impact protection +). This extra side
impact protection should be used on the doorside of the vehicle. It can be connected by
slotting between the seatshell and the fabric. The seat already offers high level integrated
side impact protection. This extra side impact protection improves the protection in the
side impact still further. Do not use the SIP+ on the seat when the space between seat
and door of the vehicle is too small, which might lead to a situation where the seat is not
positioned correctly on the vehicle seat.
Removal of the seat of the i-Size base
• The seat can be taken off by pulling the seat release handle at the front of the base.
