hours the Run Back time shall be enabled, from 1 through to 12. Fig.
3 below shows an example of a two hour Runback. After 12 the timer
shall roll over to 1 and then increment through to 12 again. The time
shall increment for every 2 seconds that the buttons are simultaneously
pressed. When one or both buttons are released it shall be assumed
that the Run Back time has been selected. Both buttons must be
released before any other button operations are allowed. The Run Back
function will not be maintained if mains power is removed and reapplied.
The Runback function will use the maximum power as defined using the ' '
button sequence and the Set Point active prior to entering Run Back mode.
The temperature Set Point may be changed by pressing the ' ' or ' ' buttons
while in Run Back Mode. The display shall flash On and Off every 5 seconds
showing the hours remaining in Runback mode, until the Runback time
has expired, then the display shall be turned off (appliance enters Standby
Mode). Please note only hours will be displayed not part of hours i.e. minutes
Delayed Start Mode
When the appliance is in Control mode and the '
' buttons are simultaneously pressed for more than 2 seconds
the appliance shall enter a 'Delayed Start' configuration menu.
The 'Delayed Start' mode will allow the appliance to turn ON after a
pre-set time. After this time has expired the appliance will turn ON and
control about the set point. The appliance shall stay ON until the mains
power is toggled or the ' ' button is pressed to place the unit in Standby.
Keeping the buttons pressed the display will indicate the number of hours
the Start Timer shall delay the appliance entering operation, from 1 through
to 12. After 12 the timer shall roll over to 1 and then increment through to
12 again. The time shall increment for every 2 seconds that the buttons
are simultaneously pressed. When one or both buttons are released it
shall be assumed that the Delayed Start time has been selected. Both
buttons must be released before any other button operations are allowed.
To indicate that the Delayed Start Timer function has been
enabled the Neon shall blink intermittently once every 10 seconds.
The Delayed Start time shall be cleared to zero when the ' ' button
is pressed, the Delayed Start timer expires or if mains power is
removed. The LCD display will display the Hours remaining in Delayed
Start mode (No Backlight) and displays hours only increments (not
minutes). Once the delayed start time has expired the appliance
enters control mode, and the display will now show the Set Point.
The Delayed Start function shall not be maintained if mains power
is removed and reapplied. The Delayed Start function shall use
the maximum power as defined using the '
and the Set Point active prior to entering Delayed Start mode.
Power Select Mode
It is possible to alter the power output of the appliance. Doing
t h i s l i m i t s t h e p o w e r o u t p u t o f t h e a p p l i a n c e , t h e r e a r e
two alternative power modes available, mid heat and low heat.
Heat Setting
LED Display
Mid
2
Low
1
To change the power mode setting it is necessary to do the following:
1. The product must be first switched off and then switched on,
this can be done by plugging in the appliance - see Fig. 4 or by
switching it on at an isolator switch. At the same time press and
hold the ' ' key for at least 2 seconds after main power is applied.
2. After power up '2' will appear on the LCD display and the standby key
can be released. '2' indicates that the appliance is in mid heat mode.
3. In order to select low level heat setting press the ' ' key within
5 seconds. The Display on the LCD should change to '1'.
4. Once the desired heat setting is reached do not press
a n y o t h e r k e y s . A f t e r a s h o r t p e r i o d t h e L C D w i l l
switch off and the appliance will revert to standby mode.
5. Pressing the ' ' button again will turn on the display and the appliance will
be in control mode. The display will toggle between the set temperature
and the power mode setting, for example between 25°C and '2'
6. In order to revert to the default Eco mode, simply switch off the
power at the wall or unplug the appliance. On the next operation
(when plugged in) it will automatically revert to Eco mode.
' and '
' button sequence
Power (W)
EvoRad 20
EvoRad 15
1200
900
800
600
Safety in use
This appliance incorporates a number of safety devices. In addition to the
'Important Safety Advice' section your attention is drawn to the following;
Tilt Switch
The tilt switch will prevent the heater from working if it is accidentally
tipped over on its side. If the radiator is tipped over while it is hot,
disconnect the power and allow it to cool, then stand the radiator back
upright. Reconnect the power - normal operation should be resumed.
Safety Overheat Protection
For your safety this appliance is fitted with a thermal cut-out. In the event
that the product overheats for some reason, the cut-out prevents excessive
temperatures on the product by cutting the power to the heater. Once
the heater has cooled down, it will reset automatically, it will continue to
cycle on and off automatically until the reason for overheating is removed.
Storage
If the heater is not required for long periods, for example during the summer,
it should be stored in a dry place and preferably covered to prevent the
accumulation of dirt and dust. The supply cord should be neatly
around the cable wrap and the plug stored in the cable wrap moulding.
Cleaning
WARNING - ALWAYS DISCONNECT THE POWER SUPPLY BEFORE
CLEANING THE HEATER.
Do not use detergents, abrasive cleaning powder or polish of any kind on
the body of the heater.
Allow the heater to cool, then wipe with a dry cloth to remove dust
and a damp cloth (not wet) to clean off stains. Be careful not to allow
moisture in to the heater.
Recycling
For electrical products sold within the European Community.
At the end of the electrical products useful life it should
not be disposed of with household waste. Please
recycle where facilities exist. Check with your Local
Authority or retailer for recycling advice in your country.
After Sales Service
Should you require after sales service, please contact the
retailer from whom the appliance was purchased or contact the
service number relevant to your country on the warranty card.
Please do not return a faulty product to us in the first instance as this may
result in loss or damage and delay in providing you with a satisfactory service.
P l e a s e r e t a i n y o u r r e c e i p t a s p r o o f o f p u r c h a s e .
Model Identifier(s):
Heat output
Nominal heat output
Minimum heat output (indicative)
Maximum continuous heat output
Auxiliary electricity Consumption
At nominal heat output
At minimum heat output
In standby mode
Type of heat output/ room temperature control
With electronic thermostat room
temperature control
Contact details
- 2 -
EvoRad15
EvoRad20
Pnom
1.5
2.0
Pmin
0.6
0.8
Pmax,c
1.5
2.0
elmax
0.0
0.0
elmin
0.0
0.0
elSB
0.0005
0.0005
Yes
Yes
Barn Road, Dunleer, Co. Louth,
Ireland, A92 WV02
coiled
kW
kW
kW
kW
kW
kW
