Contents
1. Product description..........................................................................................................3
2. Installation instructions ....................................................................................................4
3. Positioning and fixing the base........................................................................................4
4. Mounting the transmitter and receiver modules in the column ........................................4
5. Mounting the guide hoops ...............................................................................................6
6. Mounting the column on the base ...................................................................................6
7. Wiring the modules according to their instructions ..........................................................7
8. Connecting the tamper detector ......................................................................................8
9. Replacing the infrared cover............................................................................................8
10. Mounting columns back-to-back......................................................................................9
11. Dimensions and specifications ........................................................................................9
1.

Product description

The column consists of a profiled aluminium chassis of between 1 m and 3 m in height (1 m,
1.5 m, 2 m, 2.5 m, 3 m) with the elements shown below:
Top plate
Infrared cover
Staple fixing the
infrared cover
SB10/15/20/25/30 & SB11/16/21/26/31
Plug
Infrared cover
guide hoop
4 M10x16 bolts
+ 4 M10 nuts
Clips holding the
infrared cover
Aluminium profile
Bottom plate
Tamper detection
contact
3
SB Series
Column Assembly
Base option:
1 base
1 sealing
guide
4 anchor
legs
